New Panel Saw

At Nihar Industries, New Panel Saw models are designed and developed that offer a range of technical advantages over the classic panel saw machines. These machines are characterized by highly user friendly design, a sturdy and compact structure that can deliver years of robust performance even with little to no maintenance. Such features make the new panel saw machines ideal for different kinds of wood cutting projects.

The blade of this machine is titled at an angle of 45 degrees which can be further customized according to the needs of the project. The speed of the saw blade may vary between 4000 or 5000 rotations per minute, depending on the modes chosen. The design of the new panel saw table makes it quite convenient for the users to work with different types of wooden planks or PVC panels rather conveniently.

Service We Offering

Mechanical engineers use these core principles along with tools like computer-aided design, product lifecycle management to design and analyze manufacturing plants, industrial equipment and machinery, heating and cooling systems, transport systems, aircraft, robotics and medical devices.

Design Engineering

  • Component & Subsystem
  • Value Engineering
  • Material Complaince

Product Engineering

  • Seating and cockpit
  • Product Management
  • Light Weighting

Advanced Engineering

  • Component & Subsystem
  • Value Engineering
  • Material Complaince
Description Unit NR – 124-A
Sliding Table Size (L X W) mm 3200 x 435
Rip Capacity / Cutting Width mm 1250
Main Saw Section
Saw Blade Diameter mm 300(250 – 350)
Shaft Diameter mm 30
Tilting of Saw Blade Deg. 90° – 45°
Max Cutting Depth at 90° mm 75
Max Cutting Depth at 45° mm 51.5
Speed of Saw Blade RPM 3000/4000/5000
Saw Blade Motor HP 7.5/5
Scoring Saw Section
Scoring Saw Blade Diameter mm 120
Shaft of Scoring Saw mm 20
Speed of Scoring Blade mm 9000/8000
Scoring Blade Motor HP 1

*Specifications are subjected to change without notice.

  • Apply to processing all kinds of density boards, shaving boards, wood-based panels, ABS panels, PVC panels, organic glass plates and solid wood and others with wood structure and similar hardness
  • Movable table guide track is plating chromium steel balls structure, exact and durable
  • Made of high-strength extruded aluminum alloy, movable table is high in strength and wont bend
  • With oxidation treatment, movable table surface is beautiful and hardwearing
  • Tilt angles of main and scoring saw blades are displayed directly by precision inclinometer
