Hot Press Machine

Nihar Industries designs and manufactures state of the art 120 ton hot press machines that are known for their compact designs, superior pressing efficiency as well as consistent performance. The sturdy construction of the machine guarantees swift and highly accurate pressing results. The best part of choosing the hot press machines manufactured by Nihar Industries is that they are less on maintenance and can yield high productivity consistently for year after year.

The machines are equipped with advanced hydraulic systems that ensure high output with low input. The machines feature Italian made Calpeda pumps for the circulation of oil. Siemens Control System and German Hydraulic Power pack is the key features for machine excellent performance. The 42 mm plate thickness of plates ensures robust pressing results for different products. There is also a leak protection hydraulic cylinder that comes with these machines. There are also a number of other features that allow users to customize the functioning of these machines.

Capacity 120 Ton 120 Ton
No of Platen 2 Platen (Single Layer) 3 Platen (Two Layer)
Platen Size 2500 x 1300 x 42 mm+/-0.2 mm 2500 x 1300 x 42 mm+/-0.2 mm
Daylight Gap 380 mm 170 mm
Nos. of Cylinder 6 (Six) 6 (Six)
Diameter of Ram 85 mm 85 mm
Stroke of Ram 400 mm 400 mm
Heating Medium Thermic Oil Thermic Oil
Hydraulic Power 2.25 Kw(“HAVE” German Make) 2.25 Kw(“HAVE” German Make)
Heating Power 18 Kw 28 Kw
Circulating Pump Power 0.75 Kw(“Calpeda” Italian make) 0.75 Kw(“Calpeda” Italian make)
Total Power Required 21 Kw 31 Kw
Control “Siemens” PLC with “Schneider” Touch Screen HMI “Siemens” PLC with “Schneider” Touch Screen HMI

*Specifications are subjected to change without notice.

  • Heavy duty high quality fabricated steel structure
  • Leak proof hydraulic cylinder
  • Hard chrome plated rams
  • Equal heating in all daylights
  • Accurate welded and machined for minimum deflection
  • Heavy duty german power pack
  • Maintenance free hydraulic systems
  • Siemence PLC control
  • Italian Circulating pump

Applications of Hot Press Machine

Each of the Hot Press Machines that are delivered by Nihar Industries can provide with a high level of efficiency for various projects. Moreover, they can also guarantee consistent performance for a long period of time.

  • Veneer Doors
  • Laminate Doors
  • Laminate Pressing
  • Moulded Doors
  • Micra Doors
  • Veneer Pressing
